6.8 UL additional label (example)
Type 4X enclosure
NEC Class 2 only
Supply voltage: 24 V
Supply voltage device
Circuit with limited power
Degree of protection
Fig. 5: UL additional label (example)
6.9 Electrical data
WARNING!
Only circuits with limited power may be used for UL approved
components according to “NEC Class 2”.
Connections: Linear Remote Sensor:
Round cable 10 m
Rotating Remote Sensor:
Round cable 2 m shielded (maximum
extension 10 m)
Supply voltage: (via the positioner Type 8791 or Type
8792/8793)
Linear Remote Sensor:
24 V DC ± 10 %
Rotating Remote Sensor:
10 – 30 V DC
For UL devices: use „NEC Class 2“ power
supply
Power consumption: Linear Remote Sensor: < 0.3 W
Rotating Remote Sensor: < 0.8 W
Protection class: 3 as per DIN EN 61140 (VDE 0140-1)
Communication: via serial interface RS485 (included in the
supply cable)
