Burkert 8798 - Process Valve and Positioner Installation; Pneumatic Connections: Internal Air Supply

29
Fluid installation
9.4 Pneumatic connection
9.4.1 Pneumatic connection of the
Remote Sensor with internal air
supply (Type 2103, 2300 and 2301)
DANGER!
Risk of injury from high pressure in the equipment/device.
▶ Before working on equipment or device, switch off the pressure
and deaerate/drain lines.
Connection
label: 1
Connection
“Blanked off
internally,
not used”
Connection
label: 3
1
Fig. 31: Pneumatic connection with internal air supply
9.2 Installing the process valve
Thread type and dimensions can be found in the corresponding data
sheet.
→ Connect the valve according to the operating instructions for the
valve.
9.3 Installation of positioner Type
8791, Type 8792/8793
→ Connect the positioner according to the operating instructions of
Type 8791 or Type 8792/8793.
english
Type 8798
