Burmester 161 - Technical Specifications

TECHNICAL SPECIFICATIONS
34
T S
Dimensions (W x H x D)
Loft Style: 575mm x 635mm x 410mm
(22.6"x 24.8" x 16.6")
Retro Style: 635mm x 650mm x 460mm
(24.9"x 25" x 17.7")
Weight
Loft Style: 43 kg (86 lbs)
Retro Style: 31,5 kg (66.2 lbs)
Power supply
(depending on version)
120V, 60 Hz
230V, 50 Hz
Fuses F1: T1A E, F2: T250mA E
Power consumption ON: max. 460W
STBY: <1 W
OFF: <1 W
Stereo output per channel into 4 Ω 170 W
Input sensitivity re. 1 V 650 mV
Damping Factor 250
Input Impedance XLR/RCA 16 kΩ / 7.5 kΩ
Output Impedance XLR/RCA 550 Ω / 300 Ω
max. output level Analog Output 12 V
Frequency response -3dB < 10 HZ - 90 kHz (Power Amp)
10 Hz - ½ FS (DAC)
Signal-to-noise ratio > 92 dB , > 98 dB (DAC)
THD+N 1 kHz, Bw 10 Hz -22 kHz < 0,018 % , < 0,0015 % (DAC)
Gain variable
Input/Output Connectors
Analog inputs 1 Balanced XLR
Digital inputs 1 RCA, 1 TOSLINK
Analog outputs 1 x Balanced XLR, 1 x RCA
Digital outputs 1 x RCA, 1 TOSLINK
Headphone output 6.3 mm, jack
BURLINK remote control 1 x RS-232
REMOTE remote control 2 x Hohlstecker 5,5/2,5mm (DCOUT, DCIN)
Ethernet 1 x RJ-45
USB 3 x USB 2.0 type A, 1 x USB 3.0 type A,
1 x USB 2.0, type A (front)
Power supply IEC socket C14 acc. to IEC 60320-1
with mains switch
Wi-Fi antennas 2x coax connectors
Components
CD drive CD-DA
Hard disk 2 x 2 Terabytes (RAID)
Display Green point matrix, 8 characters, dimmable
