46
Figure 31: Near Boiler Piping - Heating Only
VI. Water Piping and Trim (continued)
CAUTION
It is the installers responsibility to select pumps
and boiler piping congurations that provide the
proper ow rates and performance for the boiler
and indirect water heater.
Refer to Table 12 for recommended Boiler Loop
Circulator.
