C-Nav Hardware Reference Guide
54
Mechanical Specifications
Size (L x W x H) 82.2mm (3.2”) x 340mm (13.4”) x 260mm (10.2”)
Weight 4.8 kg (10.6 lbs)
Display 10.4” TFT LCD, 1024x768, 400 nit, Resistive TS
CPU 1.0 GHz VIA 7C, 512 MB, 2GB CF
Power Input Specifications
Input Voltage 12 VDC +/- 5% (24-12VDC converter available)
Consumption 30 W
Power Supply
Size (L x W x H) 31mm (1.2”) x 110mm (4.3”) x 62mm (2.4”)
Connector Conxall, Micro-Con-X 16282-2SG-311
Input Voltage 90 – 264 VAC
Power 60 W
Frequency 47 - 63 Hz
Output Voltage 12 VDC (+/- 5%)
Operating Temperature 0º C ~ +40º C
Storage Temperature -20º C ~ +65º C
Humidity Operating: 20 ~ 80% RH; Storage: 10 ~ 90% RH
Connectors
DC Power Conxall, Micro-Con-X 17282-2PG-300
I/O Ports 4 x 9 pin RS-232 DBM (RS232-422 converter available)
Keyboard/Mouse PS/2
LAN 1 x 100/1000 Mbps
USB 2 x 2.0
VGA 1 x 15 pin DBF
Printer, Parallel 1 x 25 pin DBF
Environmental Specifications
Operating Temperature 0º C to +60º C
Storage Temperature -20º C to +85º C
Humidity 5 - 90% @ 60º C, non-condensing
