19
※While running the scooter, in case of voltage overload, the battery connection cable
set enables the scooter to automatically cut off power through circuit breakers.
※The scooter may be affected by climbing and loading, causing the circuit breaker to
automatically cut off the power. It is recommended to park on level ground or reduce
the load before repairing.
※When resetting the power breaker, please switch the main power to OFF, and then cut
off the battery power before performing the above steps to reset.
※The red connector of the power cable shall be connected to the red positive terminal;
the black connector shall be connected to the black negative terminal.
※To replace the battery, please remove the screws of each positive and negative terminal
in order.
※After the battery is installed, lock the positive and negative terminals in order; otherwise,
there is a risk of danger.
※If parking the scooter for a long time (more than one week), please fully charge the
battery, unplug the power supply, and pay attention to the placement of the power plug
to avoid short circuiting.
※After resetting, switch on to confirm that the scooter is operating normally.
※If still operating abnormally, replace with a new piece.
2.
3-3 Battery connection cable set maintenance :
※Cross Tool x 1pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Connect the battery to the cable set and push up the circuit breaker.
3.After the circuit breaker is pushed up, the reset is completed (as shown below).
3-4 Battery connection cable set disassembly :
※Hex wrench #17 x 2 pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Please refer to the 3-2 Battery removal: Untie the connection cable.
3.Remove the fixing screws (M6x16Lx2pcs) from the seat holder.
4.The battery connection cable set can now be removed.
※Please follow the above steps in reverse for reassembly and
replacement.
4.
3.
