28
5-4 Temperature sensor :
※Cross tool x 1pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Please refer to 5-1 Front slanting maintenance to remove the front slanting.
3.Remove the temperature sensor connector.
4.The temperature sensor can now be removed from the slot.
※Please follow the above steps in reverse for reassembly and replacement.
※
The temperature sensor
is fixed with the slot of
the frame. Please fix it
tightly when reassembling to
prevent it from loosening.
4.
3.
5-5 Headlight maintenance :
※Cross tool x 1pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Please refer to 5-1 Front slanting maintenance to remove the front sloping plate.
3.Remove the headlight connector.
4.Remove the front sloping cover screws (M4 x 12L x 1pcs)
5.Remove the headlights from the slot.
※Please follow the above steps in reverse for reassembly and replacement.
3.
4.
※If the headlights are faulty, please first check whether the headlight connectors and
the cable are abnormal. If they have no issue, the bulb may be burnt out. Please
replace with a new one immediately.
