•Battery electricity table :
•Charging indicating table :
Battery residual display
After the power is turned on, an alarm will be set off when the electric
quantity is lower than 30% (three beeps)
Electric
quantity
100%
6 cells
85%
5 cells
70%
4 cells
55%
3 cells
40%
2 cells
30%
(1 cell
flashes)
20% or
less
Cell
number
status
display
Warning
indicator,
continuous
flashing
Electric quantity
40%
2 cells
Loop display
55%
3 cells
Loop display
70%
4 cells
Loop display
Elect80%
5 cells Loop
displayric quantity
90%
6 cells
Loop display
100%
6 cells
Constantly on
Cell number status display
Charging indication
Incremental frequency
Remarks
Action characteristics
0.5 seconds
The cell number status display is for reference only, and the exact assessment still depends on the indicator
light on the charger.
1.The cell number only increases upwards and does not decrease.
2.The charger PIN3 (CH3) is used as the determination signal. When CH3 is grounded, it enters the charging
mode, and KEY ON or KEY OFF is not limited.
3.Press any key to turn on the backlight, which will automatically turn off if no button is touched within
five seconds.
