29
5-6 Front turn light maintenance :
※Cross tool x 1pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Please refer to 5-1 Front slanting maintenance to remove the front sloping cover.
3.Remove the front (left) turn light connector on the front box.
4.Remove the front (left) turn light screws (M4 x 12L x 3pcs)
5.Take out the front (left) turn light from the slot.
※The disassembly method of the left/right turn light is the same.
※Please follow the above steps in reverse for reassembly and replacement.
3.
4.
※If the steering light is faulty, please first check whether the steering light connectors
and the cable are abnormal. If they have no issues, the bulb may be burnt out. Please
replace with a new one immediately.
5-7 Main power switch set maintenance :
※Cross tool x 1pcs
1.Refer to 3-1 Powering off the battery to power off the scooter.
2.Please refer to 5-1 Front slanting maintenance to remove the front sloping plate.
3.Remove the main power connector.
4.Remove the main power switch set from the slot.
5.The entire set of main power switches can now be removed.
※Please follow the above steps in reverse for reassembly and replacement.
3.
※If the main power switch set is damaged, please replace with a new one immediately.
Modifying the main power switch set without permission is prohibited.
4.
5.
