Cadel nice - GENERAL INSTALLATION AND DIMENSIONS; Installation Requirements and Checks; Stove Dimensions Overview

13
NICE - MIRIAM - CRISTAL - PRETTY - KRISS - MARY - TECNA - EVO
EN
LEGEND Fig. 11 page 12
1 48,6 - 55 -57 cm
2 95 cm
3 46,6 - 47 cm
4 26,5 cm
5 17 cm
6 13,2 cm
7 Exhaust fumes d.8 cm
8 Hole combustion air inlet d.4 cm
10.3 GENERAL INSTALLATION
Fig. 12 - General installation
LEGEND Fig. 12 page 13
1 Stove
2 Minimum lateral distance = 300 mm
3 Minimum rear distance = 200 mm
4 Minimum front distance = 1000 mm
• Please check that the oor has an adequate load capacity. If the existing one does not satisfy this requirement,
appropriate measure should be provided (for example a plate for distributing the load).
• It is obligatory to install the stove away from walls and/or pieces of furniture, with a minimum air ow of 300
mm on the sides and 200 mm on the back, to enable an ecient appliance cooling and a good distribution
of heat in the room (see Fig. 12 page 13).
• For safety re regulations the distances from ammable or sensible to heat objects (sofas, pieces of furniture,
wooden covering, etc...) must be respected, has described in Fig. 12 page 13.
• If there are highly ammable objects (curtains, tted carpet, etc...), all these distances must be further
increased with 1 meter.
• If the walls are made up of ammable materials, check the safety distances (see Fig. 12 page 13).
• At maximum power check that the wall temperature does not ever exceed 80°C. If it would be necessary
please install a re resistant plate on the concerned walls.
• In some countries also masonring load-bearing walls are considered ammable.
