As this operation is so delicate it must therefore be executed by an Authorized Technician.
Fig. 34 - Fume fan cleaning: phase1 Fig. 35 - Phase 2 Fig. 36 - Phase 3
• Follow the process as describer in Fig. 34 page 26, Fig. 35 page 26 and Fig. 36 page 26.
13.7 FUME PASSAGES CLEANING
Clean the fume passages every year.
Fig. 37 - Top removal Fig. 38 - Lids removal
• Remove the top of the stove, unscrewing the screws top and rear (see Fig. 37 page 26).
• Unscrew the screws on the lids (see Fig. 38 page 26).
Fig. 39 - Fume passages cleaning Fig. 40 - Silicon laying
• Clean the fume passages with the aid of a brush (see Fig. 39 page 26).
• Lay the silicon round the hole (see Fig. 40 page 26) and screw again the lids.
• Reassemble all.
