15.2 FEATURES
DESCRIPTION NICE 7 kW MIRIAM 7 kW CRISTAL 7 kW
WIDTH 57,5 cm 51,5 cm 57,0 cm
DEPTH 48,0 cm 48,5cm 47,0 cm
HEIGHT 94,5 cm 94,5 cm 95,0 cm
WEIGHT 81-92-126 kg 74 kg 80-94 kg
INTRODUCED THERMIC POWER (Min/
Max)
2,5 - 8 kW 2,5 - 8 kW 2,5 - 8 kW
NOMINAL THERMIC POWER (Min/Max) 2,3 - 7 kW 2,3 - 7 kW 2,3 - 7 kW
EFICIENCY (Min/Max) 90 - 88,5 % 90 - 88,5 % 90 - 88,5 %
FUME TEMPERATURE (Min/Max) 95 - 180 °C 95 - 180 °C 95 - 180 °C
FUME MAXIMUM LOADING CAPACITY
(Min/Max)
3,4 - 6,41 g/s 3,4 - 6,41 g/s 3,4 - 6,41 g/s
CO EMISSIONS (13% O
2
) (Min/Max) 0,031 - 0,019 % 0,031 - 0,019 % 0,031 - 0,019 %
OGC EMISSIONS (13% O
2
) (Min/Max) 5 - 2 mg/Nm
3
5 - 2 mg/Nm
3
5 - 2 mg/Nm
3
NO
X
EMISSIONS (13% O
2
) (Min/Max) 128 - 122 mg/Nm
3
128 - 122 mg/Nm
3
128 - 122 mg/Nm
3
Medium CO CONTENTS at 13% O
2
(Min/Max)
383 - 236 mg/Nm
3
383 - 236 mg/Nm
3
383 - 236 mg/Nm
3
Medium POWDER CONTENTS at 13% O
2
(Max)
29 mg/Nm3 29 mg/Nm3 29 mg/Nm3
CHIMNEY DEPRESSION (Max) 11 Pa 11 Pa 11 Pa
MINIMUM SAFETY DISTANCE from
ammable materials
30 cm 30 cm 30 cm
ON SHARED CHIMNEY FLUE NO NO NO
FUME OUTLET DIAMETER Ø80 mm Ø80 mm Ø80 mm
COMBUSTIBLE Pellet Ø6-7 mm Pellet Ø6-7 mm Pellet Ø6-7 mm
PELLETS HEATING VALUE 5 kWh/kg 5 kWh/kg 5 kWh/kg
PELLETS HUMIDITY ≤ 10% ≤ 10% ≤ 10%
HEATING VOLUME 18/20°C Coeff.
0,045 kW (Min/Max)
55 - 168 m
3
55 - 168 m
3
55 - 168 m
3
HOURLY CONSUMPTION (Min/Max) 0,50 - 1,66 kg/h 0,50 - 1,66 kg/h 0,50 - 1,66 kg/h
HOPPER CAPACITY 18 kg 18 kg 18 kg
RANGE (Min/Max) 10,8 - 36 h 10,8 - 36 h 10,8 - 36 h
SUPPLY 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz
POWER INPUT (Max) 360 W 360 W 360 W
INGNITER RESISTANCE POWER INPUT 300 W 300 W 300 W
MINIMUM EXTERNAL AIR INLET (last
effective area)
80 cm
2
80 cm
2
80 cm
2
STOVE WITH SEALED CHAMBER NO NO NO
EXTERNAL AIR INLET FOR SEALED
CHAMBER
- - -
