NICE - MIRIAM - CRISTAL - PRETTY - KRISS - MARY - TECNA - EVO
EN
13.4 FUME CHAMBER CLEANING
Every 4/8 weeks the fume chamber cleaning must be executed.
Fig. 31 - Fume chamber Fig. 32 - Fume chamber cleaning
• Unscrew the 2 fume chamber closing zincate panel screw which stands on the back of the stove (see Fig. 31
page 25).
• Clean with a vacuum cleaner the ash which has accumulated on the inner (see Fig. 32 page 25).
• After the cleaning the opposite operation is to repeat checking the gasket efciency and integrity: if necessary
provide for its replacement by an Authorized Technician.
13.5 FUME CONDUIT CLEANING
The exhaust system must be cleaned every month.
Fig. 33 - Fume conduit cleaning
• Remove the inspection lid of the T-union (see Fig. 33 page 25).
• Extract the ash which has accumulated in the inner.
• After the cleaning repeate the opposite operation checking the integrity and eciency of the gasket: if
necessary have it replaced by an Autorized Technician.
It is important to sealed the cap othrwise noxiuous fumes will propagate among the room.
13.6 FUME FAN CLEANING
Clean every the year the fume fan from ash or dust which can cause a blade unbalance and a greater noise.
