NICE - MIRIAM - CRISTAL - PRETTY - KRISS - MARY - TECNA - EVO
EN
DESCRIPTION PRETTY 8,5 kW KRISS 8,5 kW MARY 8,5 kW
WIDTH 51,5 cm 57,0 cm 51,8 cm
DEPTH 46,5 cm 47,0 cm 46,5 cm
HEIGHT 94,5 cm 95,0 cm 99,5 cm
WEIGHT 78-86 kg 80-94 kg 75 kg
INTRODUCED THERMIC POWER (Min/
Max)
2,5 - 9,7 kW 2,5 - 9,7 kW 2,5 - 9,7 kW
NOMINAL THERMIC POWER (Min/Max) 2,3 - 8,5 kW 2,3 - 8,5 kW 2,3 - 8,5 kW
EFICIENCY (Min/Max) 90 - 88 % 90 - 88 % 90 - 88 %
FUME TEMPERATURE (Min/Max) 110 - 200 °C 110 - 200 °C 110 - 200 °C
FUME MAXIMUM LOADING CAPACITY
(Min/Max)
3,4 - 5,6 g/s 3,4 - 5,6 g/s 3,4 - 5,6 g/s
CO EMISSIONS (13% O
2
) (Min/Max) 0,031 - 0,006 % 0,031 - 0,006 % 0,031 - 0,006 %
OGC EMISSIONS (13% O
2
) (Min/Max) 5 - 1 mg/Nm
3
5 - 1 mg/Nm
3
5 - 1 mg/Nm
3
NO
X
EMISSIONS (13% O
2
) (Min/Max) 128 - 105 mg/Nm
3
128 - 105 mg/Nm
3
128 - 105 mg/Nm
3
Medium CO CONTENTS at 13% O
2
(Min/Max)
383 - 80 mg/Nm
3
383 - 80 mg/Nm
3
383 - 80 mg/Nm
3
Medium POWDER CONTENTS at 13% O
2
(Max)
11 mg/Nm
3
11 mg/Nm
3
11 mg/Nm
3
CHIMNEY DEPRESSION (Min/Max) 11 - 12 Pa 11 - 12 Pa 11 - 12 Pa
MINIMUM SAFETY DISTANCE from
ammable materials
30 cm 30 cm 30 cm
ON SHARED CHIMNEY FLUE NO NO NO
FUME OUTLET DIAMETER Ø80 mm Ø80 mm Ø80 mm
COMBUSTIBLE Pellet Ø6-7 mm Pellet Ø6-7 mm Pellet Ø6-7 mm
PELLETS HEATING VALUE 5 kWh/kg 5 kWh/kg 5 kWh/kg
PELLETS HUMIDITY ≤ 10% ≤ 10% ≤ 10%
HEATING VOLUME 18/20°C Coeff.
0,045 kW (Min/Max)
55 - 204 m
3
55 - 204 m
3
55 - 204 m
3
HOURLY CONSUMPTION (Min/Max) 0,50 - 1,90 kg/h 0,50 - 1,90 kg/h 0,50 - 1,90 kg/h
HOPPER CAPACITY 18 kg 18 kg 18 kg
RANGE (Min/Max) 9,5 - 36 h 9,5 - 36 h 9,5 - 36 h
SUPPLY 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz
POWER INPUT (Max) 360 W 360 W 360 W
INGNITER RESISTANCE POWER INPUT 300 W 300 W 300 W
MINIMUM EXTERNAL AIR INLET (last
effective area)
80 cm
2
80 cm
2
80 cm
2
STOVE WITH SEALED CHAMBER NO NO NO
EXTERNAL AIR INLET FOR SEALED
CHAMBER
- - -
