Calculated Industries MACHINIST CALC PRO User Manual

28 — Ma c h i n i s t ca l c ™ Pr o
(cont’d)
KEYSTROKE DISPLAY
OO
0.
1. Enter the Feed Rate:
325f
FEED $ 325. MM/MIN
2. Enter the Number of Teeth:
4#
TEETH $ 4.
3. Enter the Spindle Speed (RPM):
800R
RPM $ 800.
4. Calculate the Feed per Tooth:
F
* FPT 0.1016 MM
* Repeated presses of
F
will toggle through the inputs and outputs,
starting with the entered Number of Teeth.
RADIAL CHIP THINNING
In a Milling operation when the depth of a cut is less than half
the diameter of the tool, you can use the Radial Chip Thinning
to determine a new, faster and more efcient Chipload or Feed/
Tooth value.
Radial Chip Thinning –
Based on Feed per Tooth, Tool Diameter and Cut Depth
Calculate Radial Chip Thinning value with a Feed Per Tooth of
0.15 millimeters, a 25 millimeter Tool Diameter and a Cut Depth
of 2.5 millimeters:
KEYSTROKE DISPLAY
OO
0.
1. Enter the Feed per Tooth:
.15F
FPT $ 0.15 MM
2. Enter the Tool Diameter:
25d
DIA $ 25. MM
UG4089E-A-inside.indd 28 6/9/2011 3:16:17 PM

Calculated Industries MACHINIST CALC PRO Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display tilting	No
Display size (HxV)	15 x 65 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	LR44
Power source	Battery
Battery voltage	1.5 V
Number of batteries supported	2

Weight and Dimensions

Depth	25 mm
Width	90 mm
Height	160 mm
Weight	170 g
