34 — Ma c h i n i s t ca l c ™ Pr o
(cont’d)
b EXT MM 4G
b EXT MM 4H
b EXT MM 4E
b EXT MM 4F
b INT MM 4G
b INT MM 4H
3. Enter a Tolerance Grade of 6 and toggle through the available
Tolerance Positions for the entered Grade:
6gb
(Thread Class) INT MM 6H
b
EXT MM 6G
b
EXT MM 6H
b
* EXT MM 6E
* Repeated presses of
b
will continue to toggle through the available
Tolerance Positions of the specied Grade.
Thread Size
Find the available Internal and External Thread characteristics
for a M5 x 0.75 screw with a Tolerance Class of 4H.
Note: The default Metric Tolerance Class is 6H (Internal). To view the
current Tolerance Class, press
g b
after entering the desired Metric
Thread Size. To change the class, press
b
again.
KEYSTROKE DISPLAY
g *
ALL CLEAREd
1. Set Tolerance Class to Internal 4H:
4gb
(Thread Class) INT MM 4H
2. Enter the Thread Size:
5mt
SIZE 5. – MM
3. Enter the Thread Pitch and store the nal Thread Size:
.75t
THRED SIZE $ 5. – 0.75 MM
KEYSTROKE DISPLAY
