Us e r 's GU i d e — 29
3. Enter Cut Depth:
2.5gC
(RCT) DEPTH
$
2.5 MM
4. Calculate the adjusted Feed per Tooth:
C
ADJST 0.2500 MM
5. Calculate the Radial Chip Thinning Factor:
C
RCTF 1.6667
C
DIA
$
25. MM
C
FPT
$
0.15 MM
CuTTING FEED
Cutting Feed is the distance the cutting tool or workpiece
advances during one revolution of the spindle, typically measured
in millimeters per revolution. You can calculate Cutting Feed given
values for Feed per Tooth (Chip Load) and Number of Teeth. If
these values are unknown, you can calculate Cutting Feed with
Feed Rate and RPM (Spindle Speed).
Cutting Feed – Based on Feed per Tooth and # of Teeth
Calculate Cutting Feed with a Feed per Tooth (Chip Load) of
0.125 millimeters and 4 Teeth:
KEYSTROKE DISPLAY
OO
0.
1. Enter the Feed per Tooth:
.125F
FPT
$
0.125 MM
2. Enter the Number of Teeth:
4#
TEETH
$
4.
3. Calculate the Cutting Feed:
c
CUT 0.5000 MM/REV
c
FPT
$
0.125 MM
KEYSTROKE DISPLAY
(cont’d)
To Next Page
