Calculated Industries MACHINIST CALC PRO User Manual

40 — Ma c h i n i s t ca l c ™ Pr o
(cont’d)
Bolt Pattern
Calculate the Bolt Pattern for a layout with a 90 mm Diameter, a
20° Start Angle and 3 Bolts. The Center x-coordinate is 250 mm
and the center y-coordinate is 380 mm.
Note: When determining angles, 0° is at the 3 o’clock position and the
rotation goes counterclockwise.
KEYSTROKE DISPLAY
OO
0.
1. Enter the Center x-coordinate:
250ma
ADJ $ 250. MM
2. Enter the Center y-coordinate:
380mp
OPP $ 380. MM
3. Enter the Start Angle:
20n
ANGLE $ 20.°
4. Enter Bolt Circle Diameter:
90d
DIA $ 90. MM
5. Enter the Number of Bolts:
3b
BOLTS $ 3.
6. Calculate Center-to-Center Spacing and the
x and y-coordinates:
b
(Center-to-Center Spacing) OC-OC 77.9423 MM
b
X-01 292.2862 MM
b
Y-01 395.3909 MM
b
X-02 215.5280 MM
b
Y-02 408.9254 MM
b
X-03 242.1858 MM
b
Y-03 335.6837 MM
b
DIA $ 90. MM
UG4089E-A-inside.indd 40 6/9/2011 3:16:18 PM

Calculated Industries MACHINIST CALC PRO Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display tilting	No
Display size (HxV)	15 x 65 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	LR44
Power source	Battery
Battery voltage	1.5 V
Number of batteries supported	2

Weight and Dimensions

Depth	25 mm
Width	90 mm
Height	160 mm
Weight	170 g
