Chapter 4: Unit Management
Configuring Unit Parameters
phn-3963_004v000
Page 4-76
Configuring Unit Parameters
To view and configure system information:
1. Select Platform > Management > Unit Parameters. The Unit Parameters page opens.
2. Table 13 describes the fields in the Unit Parameters page.
Figure 85 Unit Parameters Page
Table 13 Unit Parameters
A name for the unit (optional). This name appears at the top of
every Web EMS page.
Descriptive information about the unit. This information is used
for debugging, and should include information such as the
chassis type.
The time since the system was last reinitialized.
The name of the person to be contacted if and when a problem
with the system occurs (optional).
The actual physical location of the node or agent (optional).
The unit's longitude coordinates.
The unit's latitude coordinates.
