Cambium Networks PTP 820C User Manual

Chapter 18: Quality of Service (QoS) (CLI)
Configuring Marking (CLI)
phn-3963_004v000
Page 18-350
Marking Table for C-VLAN UP Bits (CLI)
When marking is performed, the following table is used by the marker to decide which CoS and
Color to use as the egress CoS and Color bits for C-VLAN-tagged frames.
Table 166 Marking Table for C-VLAN UP Bits
CoS
Color
802.1q (Configurable)
CFI Color (Configurable)
0
Green
0
0
0
Yellow
0
1
1
Green
1
0
1
Yellow
1
1
2
Green
2
0
2
Yellow
2
1
3
Green
3
0
3
Yellow
3
1
4
Green
4
0
4
Yellow
4
1
5
Green
5
0
5
Yellow
5
1
6
Green
6
0
6
Yellow
6
1
7
Green
7
0
7
Yellow
7
1
To modify the 802.1q CoS and Color to UP and CFI bit mapping table, enter the following
command in root view:
root> ethernet qos 802.1q-up-bits-marking-tbl set cos <cos> color <color>
802.1p <802.1p> cfi <cfi>
To display the 802.1q CoS and Color to UP and CFI bit mapping table, enter the following
command in root view:
root> ethernet qos 802.1q-up-bits-marking-tbl show
