Chapter 17: Ethernet Services and Interfaces (CLI)
Viewing Ethernet PMs and Statistics (CLI)
phn-3963_004v000
Page 17-318
Configuring Ethernet Port PMs and PM Thresholds (CLI)
To enable the gathering of PMs for an Ethernet interface, go to interface view for the interface and
enter the following command:
eth type eth [x/x]> pm set admin <enable|disable>
You can configure thresholds and display the number of seconds these thresholds were exceeded
during a specified interval.
To configure interface PM thresholds, go to interface view for the interface and enter the following
command:
eth type eth [x/x]> pm set thresholds rx-layer1-rate-threshold <0-
4294967295> tx-layer1-rate-threshold <0-4294967295>
To display whether or not PM gathering is enabled for an Ethernet interface, as well as the
configured thresholds, go to interface view for the interface and enter the following command:
eth type eth [x/x]> pm show configuration
Table 143 Port PM Thresholds CLI Parameters
The exceed threshold for port RX
PMs, in bytes per second.
The exceed threshold for port TX
PMs, in bytes per second.
The following commands bring you to interface view for Ethernet port 1, enable PM gathering, and
set the thresholds for RX and TX PMs at 850,000,000 bytes per second:
root> ethernet interfaces eth slot 1 port 1
eth type eth [1/1]>pm set admin enable
eth type eth [1/1]>pm set thresholds rx-layer1-rate-threshold 850000000
tx-layer1-rate-threshold 850000000
Displaying Ethernet Port PMs (CLI)
Note
The port PM results may be several pages long. Remember:
To view the next results page, press the space bar.
To end the list and return to the most recent prompt, press the letter q.
