CX input
Associate a function with the CX input.
F2 CX input OFF (Default)
C1 = Reopen while closing (photocells)
C2 = Reclose while opening (photocells)
C3 = Partial stop Only with [Automatic close] activated.
C4 = Obstacle standby (photocells)
C7 = Reopen while closing (sensitive edges)
C8 = Reclose while opening (sensitive edges)
C13 = Reopen while closing, with immediate stop once
the obstruction has been removed, even if the gate is not
in motion
r7 = Reopen while closing (sensitive edges with 8K2
resistor)
r8 = Reclose while opening (sensitive edges with 8K2
resistor)
2r7 = Reopen while closing (pair of sensitive edges with
8K2 resistor)
2r8 = Reclose while opening (pair of sensitive edges with
8K2 resistor)
CY input
Associate a function with the CY input.
F3 CY input OFF (Default)
C1 = Reopen while closing (photocells)
C2 = Reclose while opening (photocells)
C3 = Partial stop Only with [Automatic close] activated.
C4 = Obstacle standby (photocells)
C7 = Reopen while closing (sensitive edges)
C8 = Reclose while opening (sensitive edges)
C13 = Reopen while closing, with immediate stop once
the obstruction has been removed, even if the gate is not
in motion
r7 = Reopen while closing (sensitive edges with 8K2
resistor)
r8 = Reclose while opening (sensitive edges with 8K2
resistor)
2r7 = Reopen while closing (pair of sensitive edges with
8K2 resistor)
2r8 = Reclose while opening (pair of sensitive edges with
8K2 resistor)
