CAME FROG-MD

1
4
6
3
2
7
8
9
10
5
11
5
4
8
1
8
7
9
10
6
2
3
3
11
11
11
Page
4
4 - Manual code:
FA00598-EN
FA00598-EN ver.
1
1 05/2018 © CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
Description of the components
1. Tie rod
2. Motor arm
3. Gearmotor
4. Cover
5. Foundation box
6. Upper arm
7. Arm unit
8. Brass
9. Casing hole cover
10. Mechanical stop
11. Limit switch
Example of a system
1. Right-hand gearmotor with foundation box
2. Left-hand gearmotor with foundation box
3. Junction box
4. Control panel
5. Antenna
6. Flashing light
7. Key selector
8. Photocells
9. Inspection chamber
10. Drainage chamber
11. Mechanical stop
