CAME FROG-MD - Electrical Connections Overview; Three-Phase 400 V Power Supply Wiring; Star Connection Diagram

R S T N
A B GND
R S T N
U W V X W Y E1 E2
U W V X W Y E1 E2
R
ST
ZM3ES
Page
10
10 - Manual code:
FA00598-EN
FA00598-EN ver.
1
1 05/2018 © CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
M1 - Delayed opening gearmotor. M2 -
Delayed closing gearmotor.
Three-phase 400 VAC -
50/60 Hz power supply
3P + N +
 BROWN
 BLACK
 BLUE
 YELLOW / GREEN
Three-phase 400 V power supply
YELLOW / GREEN
BROWN
BLACK
BLUE
YELLOW / GREEN
BROWN
BLACK
BLUE
IP67 junction boxes (not
supplied)
Star connection
⚠
For electrical connection operations follow the information in the control panel technical documents.
ELECTRICAL CONNECTIONS
