CAME FROG-MD - Three-Phase 230 V Power Supply Wiring; Delta Connection Diagram

R S T N
U W V X W Y E1 E2
R
ST
A B GND
R S T N
U W V X W Y E1 E2
ZM3ES
Page
11
11 -
Manual code:
FA00598-EN
FA00598-EN ver.
1
1 05/2018
© CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
Three-phase 230 VAC -
50/60 Hz power supply
3P + N +
 BROWN
 BLACK
 BLUE
 YELLOW / GREEN
YELLOW / GREEN
BROWN
BLACK
BLUE
YELLOW / GREEN
BROWN
BLACK
BLUE
IP67 junction boxes (not
supplied)
Delta connection
M1 - Delayed opening gearmotor. M2 - Delayed closing gearmotor.
Three-phase 230 V power supply
