CAME FROG-MD - Limit-Switch Gearmotor Wiring; Control Panel End Stop Configuration; End Stop Configuration Verification

U W V X W Y E1 E2
2 FA1 FC1 FA2 FC2
A B GND
R S T N
U W V X W Y E1 E2
X 12
X 13
Page
12
12 - Manual code:
FA00598-EN
FA00598-EN ver.
1
1 05/2018 © CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
ZM3ES
YELLOW / GREEN
GREY
BLACK
YELLOW / GREEN
GREY
BLACK BLACK
GREY
YELLOW / GREEN
BLACK
GREY
YELLOW / GREEN
< FUNCTIONS >
< Confi g. >
end stop
< FUNCTIONS >
< end stop >
NC
 YELLOW / GREEN
 GREY
 BLACK
 BLUE
 BROWN
IP67 junction boxes (not
supplied)
 On the control panel, select and confirm <end stop> from the Configuration feature.
Make sure that the <end stop> feature is configured to N.C.
M1 - Delayed opening gearmotor. M2 - Delayed closing gearmotor.
Connecting limit-switch-fitted gearmotors
 Opening limit-switch (M1)
 Closing limit-switch (M1)
 Closing limit-switch (M2)
 Opening limit-switch (M2)
