10
Reference page numbers are indicated by (p.∗∗).
Nomenclature
DIGITAL
terminal (p.100)
VIDEO OUT
terminal (p.93)
Remote control
terminal
(for Remote
Switch RS-60E3)
Hot shoe
EF lens mount index (p.23)
EF-S lens mount index
(p.23)
Grip
(
Battery
compartment
)
Remote control
sensor
DC coupler cord
hole (p.22)
Flash-sync contacts
Shutter button
(p.26)
Mode dial (p.14)
Lens lock pin
Lens mount
Contacts (p.9)
Depth-of-field
preview button
(p.71)
Built-in flash (p.80)
Red-eye
reduction
/Self-timer lamp
(p.82/44)
Strap mount
(p.17)
Lens release
button (p.23)
Mirror (p.34)
Drive mode selection
button (p.65)
〈M〉 Flash
button (p.83)
〈l〉 Main dial
(p.27)
EF-S18-55mm f/3.5-5.6 lens
Power switch (p.26)
Focus mode switch
Lens mount index
Contacts (p.9)
Hood EW-60C
(optional) mount
58 mm filter
thread
(front of lens)
Focusing ring
Zoom ring
