Table 66 – Booklet Finisher AC1 and Staple Finisher-AC1 Specifications
Item
Specifications
Paper Size/Weight/Type
84
Size
13" x 19", 12 5/8" x 17 11/16", 12"x18", 11"x17", LGL, LTR, LTRR,
STMTR, EXEC, and Custom size (5 1/2" x 5 7/8" to 13" x 19 1/4" (139.7
mm x 148 mm to 330.2 mm x 487.7 mm))
Notes:
• If the Long Sheet Feeding and Catch Tray-B1 is attached, the size is
from
3 7/8" x 5 7/8" to 13" x 51 1/4" (98.4 mm x 148 mm to 330.2 mm x
1,300 mm).
• Long sheet can only be output to Tray C. To use long sheet, press
[Function Settings] → [Common] → [Paper Output Settings] →
[Output Tray Settings] (Settings/Registration), and then set the output
destination to [Tray C].
Weight
Tray A, Tray B: 14 lb bond to 140 lb index (52 g/m
2
to 256 g/m
2
)
Tray C: 14 lb bond to 110 lb cover (52 g/m
2
to 300 g/m
2
)
Type
Thin, Plain, Heavy 1, Heavy 2, Heavy 3, Heavy 4, Heavy 5, Heavy 6,
Color, Recycled, Pre-Punched, Transparency, Tracing, Labels, Tab,
Bond, Letterhead, and Coated, Textured, Vellum and Envelopes
Capacity Per Tray
(Tray A / Tray B)
No Collating/Collate/Group
• LTR, STMTR, EXEC: 250 sheets (or 1 7/8" (47 mm) in height)
• 13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL and LTRR:
125 sheets (or 1" (24 mm) in height)
No Collating/Collate/Group mode with different paper sizes
• LTR: 250 sheets (or 1 7/8" (47 mm) in height)
• All other combinations: 125 sheets (or 1" (24 mm) in height or less)
• Paper with the length of 17" (431.9 mm) or more: 30 sheets
Offset mode (Collate/Group)
• LTR, EXEC, A4, B5, and 16K: 250 sheets (or 1 7/8" (47 mm) in
height)
• 11" x 17", A3, B4, and 8K: 125 sheets (or 1" (24 mm) in height or
less)
Capacity Per Tray
(Tray C)
No Collating/Collate/Group
17 lb bond / 20 lb bond / 21 lb bond (64 g/m² / 75 g/m² / 80 g/m²)
• LTR, STMTR and EXEC: 3,000 sheets (or 16 5/8" (423 mm) in
height)
89
• 13" x 19", 12 5/8" x 17 11/16", 12" x 18", 11" x 17", LGL and LTRR:
1,500 sheets (or 8 1/2" (216 mm) in height)
Envelopes
• Monarch: 30 sheets
• Other than Monarch: 100 sheets
Long Paper (When the Long Sheet Tray-B is attached)
• 19 1/4" to 30" (487.7 mm to 762 mm): 100 sheets (21 lb bond (80
g/m
2
))
• 30 1/8" (762.1 mm) or more: 1 sheet
No Collating/Collate/Group mode with different paper sizes
• LTR 3,000 sheets (or 16 5/8" (423 mm) in height)
• All other combinations: 1,500 sheets (or 8 1/2" (216 mm) in height)
89 Up to 1,500 sheets (or 8 1/2" (216 mm) in height) when thin paper or custom paper lighter than 15.7 lb bond (59 g/m2) is
selected
