Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 105
Table 66 – Booklet Finisher AC1 and Staple Finisher-AC1 Specifications
Continued
Item
Specifications
Capacity Per Tray
(Tray C)
Offset mode (Collate/Group)
• LTR and EXEC: 3,000 sheets (or 16 5/8" (423 mm) in height)
*1
• 11" x 17", LGL and LTRR: 1,500 sheets (or 8 1/2" (216 mm) in
height)
Z-Fold mode (when the Document Insertion / Folding Unit-K is
attached)
• 11" x 17": 30 sheets (or 8 1/2" (216 mm) in height)
• LGL and LTRR: 10 sheets
Staple mode (Corner/Double)
• LTR and EXEC: 200 sets, or total 3,000 sheets (or 16 5/8" (423
mm) in height)
*2
• 11" x 17", LGL, LTRR, A3, B4, A4R, and 8K: 100 sets, or total
1,500 sheets (or 8 1/2" (216 mm) in height)
Staple-Free (Eco)
• 11" x 17" and LTR: 200 sets
*1 Thin (14 lb bond to 17 lb bond (52 g/m² to 63 g/m²)): 1,500 sheets (or
8 1/2" (216 mm) in height)
*2 Thin (14 lb bond to 17 lb bond (52 g/m² to 63 g/m²)): 100 sets, or
total 1,500 sheets (or 8 1/2" (216 mm) in height)
Maximum Stapling
Capacity/Available
Staple Size
When the standard staple cartridge is attached. (The maximum stapling
capacity may vary, depending on the paper type and weight.)
Corner / Double
• LTR and EXEC:
• 65 sheets (14 lb bond to 24 lb bond (52 g/m
2
to 90 g/m
2
))
• 50 sheets (25 lb bond to 27 lb bond (91 g/m
2
to 105 g/m
2
))
• 2 sheets (28 lb bond to 95 lb cover (106 g/m
2
to 256 g/m
2
))
• 11" × 17", LGL and LTRR:
• 40 sheets (14 lb bond to 24 lb bond (52 g/m
2
to 90 g/m
2
))
• 30 sheets (25 lb bond to 27 lb bond (91 g/m
2
to 105 g/m
2
))
• 2 sheets (28 lb bond to 95 lb cover (106 g/m
2
to 256 g/m
2
))
Staple-Free (Eco)
• 5 sheets (13.8 lb bond to 17 lb bond (52 g/ m
2
to 64 g/m
2
))
• 4 sheets (17.3 lb bond to 21.7 lb bond (65 g/ m
2
to 81.4 g/m
2
))
• 3 sheets (21.8 lb bond to 27.9 lb bond (82 g/ m
2
to 105 g/m
2
))
Manual Staple
• 65 sheets (14 lb bond to 24 lb bond (52 g/m
2
to 90 g/m
2
))
• 50 sheets (25 lb bond to 27 lb bond (91 g/m
2
to 105 g/m
2
))
• 2 sheets (28 lb bond to 95 lb cover (106 g/m
2
to 256 g/m
2
))
2/3 Hole Puncher Unit-A1
(When the puncher unit is
attached)
Paper Sizes:
• 2 Holes: 11" x 17", LGL, LTRR, LTR and EXEC
• 3 Holes: 11" x 17", LTR and EXEC
Paper Weight: 14 lb bond to 110 lb cover (52 g/m
2
to 300 g/m
2
)
Punch Holes: 2/3 Holes
84 Reference Registered Paper Types and Weight for the available paper weights.
