Chapter 5
5-1
5.1 Periodic Replacement Parts
5.1.1 Periodic Replacement Parts
0013-6993
T-5-1
5.2 Consumable Parts
5.2.1 Consumable Parts
0017-5585
T-5-2
After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service
mode to initialize (clear) the parts counter information.
Level Periodic Replacement part
User None
Service Personnel None
Consumables Service Mode
Name Part number Q'ty
Life
sheets
/A0
PARTS
xx
COUNTER
x
States (Error Code)
Service WASTE INK
TANK UNIT
QM3-1369-030 2 12000 A1/A2
A OK/W1/E146-4001
MIST FAN QL2-1053-000 2 12000 A1/A2
ABSORBER,
DUCT
QC2-2999-000 2 12000 A1/A2
BASE, MULTI
SENSOR
REFERENCE
QL2-1738-000 1 12000 A2
CARRIAGE UNIT QM3-3330-000 1 12000 D1/D2/
D3
DOK/W1/W2
SCALE, LINEAR QC2-2697-000 1 12000 D2
TUBE UNIT QM3-3329-000 1 12000 F1 F OK/W1/W2
PURGE UNIT QM3-1413-000 1 12000 H1 H OK/W1/E141-4046
HEAD
MANAGEMENT
SENSOR UNIT
QM3-1395-000 1 12000 K1 K OK/W1/W2//E194-
404A
MOTOR,
CARRIAGE
QM3-1401-000 1 12000 M1 M OK/W1/W2
User See "Product Overview> Features> Consumables"
