Chapter 5
5-5
- Do not dry the interiors of the top cover with a dry cloth. Electrostatic charges could make the internal
components susceptible to dirt, resulting in degraded print quality.
- Do not use flammable solvents, such as thinner and benzine, on the printer. Solvents coming into contact with
any electrical parts inside the printer could result in fires or electrical shock hazards.
- Do not touch linear scale [1] and carriage shaft [2].
F-5-4
9) Remove the roll feed unit and fold plain paper two to three times and then insert through the printer rear into
the underside of the pinch roller unit to wipe off dirt on the pinch roller unit.
[2]
[1]
To Next Page
