Canon iPF710 - Page 168

Chapter 6
6-5
T-6-8
T-6-9
T-6-10
T-6-11
J2702
Pin
Number
Signal name IN/OUT Function
1 VM 26V OUT Power supply (+26V)
2 DCOVER_SOL OUT Upper cover lock solenoid (L) drive signal
J2703
Pin
Number
Signal name IN/OUT Function
1 VM 26V OUT Power supply (+26V)
2 DCOVER_SOL OUT Upper cover lock solenoid (R) drive signal
3N.C - N.C
J2704
Pin
Number
Signal name IN/OUT Function
1 VM_26V OUT Power supply (+26V)
2 KYUINFAN_ALARM IN Suction fan alarm signal
3 KYUINFAN_PWM OUT Suction fan duty control signal
4 GND - GND
5 VM_26V OUT Power supply (+26V)
6 MISTFAN_R_ALARM IN Mist fan (R) alarm signal
7 GND - GND
8 VM_26V OUT Power supply (+26V)
9 MISTFAN_L_ALARM IN Mist fan (L) alarm signal
10 GND - GND
11 VM_26V OUT Power supply (+26V)
12 SPOOL_CL OUT Roll media rewinding cluch drive signal
13 /ATUKAIJYO IN Pressure release switch output signal
14 GND - GND
J2801
Pin
Number
Signal name IN/OUT Function
1 LFSP_A OUT Feed motor drive signal A
2 LFSP_VM OUT Power supply (+32V)
