Canon iPF710 - Page 169

Chapter 6
6-6
T-6-12
T-6-13
T-6-14
T-6-15
3 LFSP_AB OUT Feed motor drive signal AB
4 LFSP_BB OUT Feed motor drive signal BB
5 LFSP_VM OUT Power supply (+32V)
6 LFSP_B OUT Feed motor drive signal B
J3001
Pin
Number
Signal name IN/OUT Function
1 VM OUT Power supply (+32V)
2- - -
J3004
Pin
Number
Signal name IN/OUT Function
1- - -
2 VM_CR IN Upper cover lock switch output signal
3 N.C - N.C
J3101
Pin
Number
Signal name IN/OUT Function
1 CRM_C OUT Carriage motor phase drive signal (C)
2 CRM_B OUT Carriage motor phase drive signal (B)
J3201
Pin
Number
Signal name IN/OUT Function
1 TANK_CLK OUT Ink tank clock signal
2 GND - GND
3 TANK_DAT2 IN/OUT Ink tank data signal 2
4 TANK_ON(+3.3V) OUT Power supply (+3.3V)
5 TANK_DAT1 IN/OUT Ink tank data signal 1
6 TANK_DAT0 IN/OUT Ink tank data signal 0
J2801
Pin
Number
Signal name IN/OUT Function
