Canon iPF710 - Page 170

Chapter 6
6-7
T-6-16
T-6-17
T-6-18
7 GND - GND
8 INK_DETECT0 IN Ink detection sensor output signal 0
9 INK_DETECT1 IN Ink detection sensor output signal 1
10 INK_DETECT2 IN Ink detection sensor output signal 2
J3202
Pin Number Signal name IN/OUT Function
1 TANK_CLK OUT Ink tank clock signal
2 GND - GND
3 TANK_DAT8 IN/OUT Ink tank data signal 8
4 TANK_ON(+3.3V) OUT Power supply (+3.3V)
5 TANK_DAT7 IN/OUT Ink tank data signal 7
6 TANK_DAT6 IN/OUT Ink tank data signal 6
7 GND - GND
8 INK_DETECT6 IN Ink detection sensor output signal 6
9 INK_DETECT7 IN Ink detection sensor output signal 7
10 INK_DETECT8 IN Ink detection sensor output signal 8
11 N.C - N.C
J3301
Pin Number Signal name IN/OUT Function
1 MENT_SDA IN/OUT Maintenance cartridge ROM control signal (data)
2 MENT_SCL IN/OUT Maintenance cartridge ROM control signal (clock)
3 GND - GND
4 +3.3V OUT Power supply (+3.3V)
5 N.C - N.C
J3401
Pin
Number
Signal name IN/OUT Function
1 VMGND - GND
2 VMGND - GND
3 VMGND - GND
4 VMGND - GND
J3201
Pin
Number
Signal name IN/OUT Function
