Chapter 6
6-8
T-6-19
5 VH_MONI1 IN VH control signal 1
6 VH_ENB OUT VH power supply ON/OFF signal
7 VH_MONI2 IN VH control signal 2
8 GND - GND
9 +3.3V OUT Power supply (+3.3V)
10 +3.3V OUT Power supply (+3.3V)
11 GND - GND
12 SNS5V OUT Power supply (+5V)
13 SNS5V OUT Power supply (+5V)
14 VM OUT Power supply (+32V)
15 VM OUT Power supply (+32V)
16 VM OUT Power supply (+32V)
17 VM OUT Power supply (+32V)
18 VM OUT Power supply (+32V)
19 VM OUT Power supply (+32V)
20 VM OUT Power supply (+32V)
21 VM OUT Power supply (+32V)
22 VMGND - GND
23 VMGND - GND
24 VMGND - GND
25 VMGND - GND
J3601
Pin
Number
Signal name IN/OUT Function
1 GND - GND
2 H1-D-DATA-7-OD_B OUT Odd head data signal 7(D)
3 GND - GND
4 H1-E-HE-8_B OUT Head heat enable signal 8(E)
5 GND - GND
6 H1-E-DATA-8-EV_B OUT Even head data signal 8(E)
7 GND - GND
8 H1-F-DATA-10-OD_B OUT Odd head data signal 10(F)
9 GND - GND
10 H1-E-DATA-9-OD_B OUT Odd head data signal 9(E)
11 GND - GND
12 H1-F-HE-10_B OUT Head heat enable signal 10(F)
13 GND - GND
J3401
Pin
Number
Signal name IN/OUT Function
