Chapter 6
6-9
14 H1-F-DATA-11-OD_B OUT Odd head data signal 11(F)
15 GND - GND
16 H1-F-HE-11_B OUT Head heat enable signal 11(F)
17 GND - GND
18 H1-F-DATA-11-EV_B OUT Even head data signal 11(F)
19 GND - GND
20 H1-F-DATA-10-EV_B OUT Even head data signal 10(F)
21 GND - GND
22 H1-E-HE-9_B OUT Head heat enable signal 9(E)
23 GND - GND
24 H1-E-DATA-9-EV_B OUT Even head data signal 9(E)
25 GND - GND
26 H1-B-DATA-2-OD_B OUT Odd head data signal 2(B)
27 GND - GND
28 H1-B-DATA-3-OD_B OUT Odd head data signal 3(B)
29 GND - GND
30 H1-C-HE-4_B OUT Head heat enable signal 4(C)
31 GND - GND
32 H1-C-DATA-4-OD_B OUT Odd head data signal 4(C)
33 GND - GND
34 H1-B-HE-2_B OUT Head heat enable signal 2(B)
35 GND - GND
36 H1-A-DATA-1-OD_B OUT Odd head data signal 1(A)
37 GND - GND
38 H1-A-DATA-0-OD_B OUT Odd head data signal 0(A)
39 GND - GND
40 PWLED2_ON OUT Multi sensor LED2 drive signal
41 PWLED3_ON OUT Multi sensor LED3 drive signal
42 PWLED1_ON OUT Multi sensor LED1 drive signal
43 PWLED4_ON OUT Multi sensor LED4 drive signal
44 /CR_COVER IN Carriage cover sensor output signal
45 VH_DIS OUT VH selection signal
46 /OUT_ENB OUT Head data enable signal
47 /H3V_ON_B OUT Power supply (+3V)
48 MLT_SENS_1IN IN Multi sensor signal 1
49 MLT_SENS_2IN IN Multi sensor signal 2
50 GND - GND
J3601
Pin
Number
Signal name IN/OUT Function
