Canon iPF710 - Page 173

Chapter 6
6-10
T-6-20
J3602
Pin
Number
Signal name IN/OUT Function
1 GND - GND
2 H1-E-DATA-8-OD_B OUT Odd head data signal 8(E)
3 GND - GND
4 H1-D-HE-7_B OUT Head heat enable signal 7(D)
5 GND - GND
6 H1-D-DATA-7-EV_B OUT Even head data signal 7(D)
7 GND - GND
8 H1-D-DATA-6-EV_B OUT Even head data signal 6(D)
9 GND - GND
10 H1-D-DATA-6-OD_B OUT Odd head data signal 6(D)
11 GND - GND
12 H1-D-HE-6_B OUT Head heat enable signal 6(D)
13 GND - GND
14 H1-C-HE-5_B OUT Head heat enable signal 5(C)
15 GND - GND
16 H1-C-DATA-5-OD_B OUT Odd head data signal 5(C)
17 GND - GND
18 H1_CLK_B OUT Head clock signal
19 GND - GND
20 /H1_LT_B OUT Head latch signal
21 GND - GND
22 H1-C-DATA-5-EV_B OUT Even head data signal 5(C)
23 GND - GND
24 H1-B-HE-3_B OUT Head heat enable signal 3(B)
25 GND - GND
26 H1-C-DATA-4-EV_B OUT Even head data signal 4(C)
27 GND - GND
28 H1-B-DATA-3-EV_B OUT Even head data signal 3(B)
29 GND - GND
30 H1-B-DATA-2-EV_B OUT Even head data signal 2(B)
31 GND - GND
32 H1-A-DATA-1-EV_B OUT Even head data signal 1(A)
33 GND - GND
34 H1-A-HE-1_B OUT Head heat enable signal 1(A)
35 GND - GND
36 H1-A-DATA-0-EV_B OUT Even head data signal 0(A)
37 GND - GND
38 H1-A-HE-0_B OUT Head heat enable signal 0(A)
39 GND - GND
