Chapter 6
6-11
40 /ENCODER_A IN Carriage encoder output signal A
41 /ENCODER_B IN Carriage encoder output signal B
42 H-DASH_LICC2_B OUT Head analogue switch A/D trigger signal
43 H1-DASLK_LICC2 OUT Head analogue switch clock signal
44 H1-DLD_LICC2 OUT Head analogue switch latch signal
45 H1-DATA_LICC2 OUT Head analogue switch data signal
46 H1-DSOUT2 IN Head temperature output signal 2
47 H1-DSOUT1 IN Head temperature output signal 1
48 IO_ASIC_SCL_B IN/OUT Head ROM control signal (clock)
49 IO_ASIC_SDA IN/OUT Head ROM control signal (data)
50 GND - GND
J3602
Pin
Number
Signal name IN/OUT Function
