Canon iPF710 - Page 180

Chapter 6
6-17
T-6-27
J702
Pin Number Signal name IN/OUT Function
1 MLT_SNS_2IN IN Multi sensor signal 2
2 MLT_SNS_1IN IN Multi sensor signal 1
3 H1-C-DATA-4-OD OUT Odd head data signal 4(C)
4 /H1-C-HE-4 OUT Head heat enable signal 4(C)
5 H1-B-DATA-3-OD OUT Odd head data signal 3(B)
6 H1-B-DATA-2-OD OUT Odd head data signal 2(B)
7 /H1-B-HE-2 OUT Head heat enable signal 2(B)
8 H1-A-DATA-1-OD OUT Odd head data signal 1(A)
9 H1-A-DATA-0-OD OUT Odd head data signal 0(A)
10 /H1-A-HE-0 OUT Head heat enable signal 0(A)
11 H1-A-DATA-0-EV OUT Even head data signal 0(A)
12 H1-A-DATA-1-EV OUT Even head data signal 1(A)
13 /H1-A-HE-1 OUT Head heat enable signal 1(A)
14 H1-B-DATA-2-EV OUT Even head data signal 2(B)
15 H1-B-DATA-3-EV OUT Even head data signal 3(B)
16 /H1-B-HE-3 OUT Head heat enable signal 3(B)
17 H1-C-DATA-4-EV OUT Even head data signal 4(C)
18 /H1_LT OUT Head latch signal
19 H1-C-DATA-5-EV OUT Even head data signal 5(C)
20 /H1-C-HE-5 OUT Head heat enable signal 5(C)
21 H1-C-DATA-5-OD OUT Odd head data signal 5(C)
22 H1_CLK OUT Head clock signal
23 H1-D-DATA-7-OD OUT Odd head data signal 7(D)
24 H1-D-DATA-6-OD OUT Odd head data signal 6(D)
25 /H1-D-HE-6 OUT Head heat enable signal 6(D)
26 H1-D-DATA-6-EV OUT Even head data signal 6(D)
27 H1-D-DATA-7-EV OUT Even head data signal 7(D)
28 /H1-D-HE-7 OUT Head heat enable signal 7(D)
29 H1-E-DATA-8-EV OUT Even head data signal 8(E)
30 H1-E-DATA-9-EV OUT Even head data signal 9(E)
31 /H1-E-HE-9 OUT Head heat enable signal 9(E)
32 H1-F-DATA-10-EV OUT Even head data signal 10(F)
33 H1-F-DATA-11-EV OUT Even head data signal 11(F)
34 /H1-F-HE-11 OUT Head heat enable signal 11(F)
35 H1-F-DATA-11-OD OUT Odd head data signal 11(F)
36 H1-F-DATA-10-OD OUT Odd head data signal 10(F)
37 /H1-F-HE-10 OUT Head heat enable signal 10(F)
38 H1-E-DATA-9-OD OUT Odd head data signal 9(E)
39 H1-E-DATA-8-OD OUT Odd head data signal 8(E)
