40 /H1-E-HE-8 OUT Head heat enable signal 8(E)
41 GND - GND
42 H1_DSOUT1 IN Head temperature output signal 1
43 H1_DSOUT2 IN Head temperature output signal 2
44 H1-DLD_LICC2 OUT Head analogue switch latch signal
45 H1-DATA-LICC2 OUT Head analogue switch data signal
46 H1-DASLK_LICC2 OUT Head analogue switch clock signal
47 H1-DASH_LICC2 OUT Head analogue switch A/D trigger signal
48 SNS5V OUT Power supply (+5V)
49 IO-ASIC_SDA IN/OUT Head ROM control signal (data)
50 IO-ASIC_SCL IN/OUT Head ROM control signal (clock)
J702
Pin Number Signal name IN/OUT Function
