When you place a checkmark on Auto Settings, the one-page length to be printed on roll paper is automati-
cally set so that the laid-out objects are printed on one page.
Note
• Available only if rolls are selected in Paper Source.
• You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
•
Order
Set the object layout order.
The following settings are available for order.
Setting Details
Upper Left to Right The objects are laid out from upper left to right.
Upper Left to Bottom The objects are laid out from upper left to bottom.
Note
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Vertical, you can
choose only Upper Left to Right.
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Horizontal, you can
choose only Upper Left to Bottom.
•
Paper Size
You can select the size of the print media.
Note
• You cannot display this if Roll Paper is selected in Paper Source.
Zoom Dialog Box
Zoom Dialog Box
This dialog box appears when you select Zoom from the View menu. You can enlarge or reduce the screen dis-
play.
•
Scaling
Set the magnification for enlargement or reduction of the screen display.
Note
• You can input between 10 and 400.
• You can change the numbers by clicking ▼ button.
Zoom Dialog Box
iPF8400SE
User's Guide
Mac OS Software Free Layout
302
