Printer parts
Printer parts
Front ......................................................................................................................................................................................462
Back .......................................................................................................................................................................................464
Top Cover (Inside) ........................................................................................................................................................... 465
Carriage ............................................................................................................................................................................... 466
Ink Tank Cover (Inside) ................................................................................................................................................. 467
Stand ..................................................................................................................................................................................... 468
Output Stacker ................................................................................................................................................................. 469
Control Panel ..................................................................................................................................................................... 428
Front
Front
a
Top Cover
Open this cover to install the Printhead, load paper, and remove any jammed paper from inside the printer as
needed. (See "Top Cover (Inside).") âž” P.465
b
Cutter Groove
Paper is cut (using the cutter or manually with scissors) over this groove.
c
Ejection Guide
Guides printed documents as they are ejected. Raise the guide when loading a roll.
d
Roll Holder Slot
Slide the Roll Holder into this slot.
e
Roll Holder
Load the roll on this holder.
f
Ejection Support
Prevents printed documents from winding around the Roll Holder or being drawn into the Paper Feed Slot.
Front
iPF8400SE
User's Guide
Printer Parts Printer parts
462
