Printheads
Printheads
Printhead ............................................................................................................................................................................. 545
Checking for Nozzle Clogging ....................................................................................................................................545
Cleaning the Printhead .................................................................................................................................................. 546
Replacing the Printhead ............................................................................................................................................... 547
Printhead
Printhead
When purchasing, check the Model number.
Shape Model number
PF-05
Note
• For instructions on replacing the Printhead, see "Replacing the Printhead." ➔ P.547
Checking for Nozzle Clogging
Checking for Nozzle Clogging
If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a
test pattern to check the nozzles.
Note
• By default, nozzles are checked at fixed intervals.
Configure the settings on the Control Panel menu in Nozzle Check.
(See "Menu Settings.") ➔P.446
Paper to Prepare
When Using Rolls An unused roll at least 254.0 mm (10.00 in) wide
When Using Sheets One sheet of unused paper of at least A4/Letter size
1
Load paper.
•
Loading Rolls on the Roll Holder âž” P.337
•
Loading Rolls in the Printer âž” P.339
•
Loading Sheets in the Printer âž” P.360
2
On the Tab Selection screen of the Control Panel, press â—€ or â–¶ to
select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
iPF8400SE
Printhead
User's Guide
Maintenance and Consumables Printheads
545
To Next Page
