2
Press â–² or â–¼ to select "Load Roll Paper", and then press the OK button.
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press â–² or â–¼ to select Yes, and then press the OK button. Remove the paper and go to the next step.
3
Open the Top Cover and lift the Ejection Guide.
4
Holding the Roll Holder so that the side with the white
gear faces the side of the Roll Holder Slot with a
white gear, load the Roll Holder shaft (a) into the
grooves (b) on both ends of the Roll Holder Slot, fully
into the slot.
Caution
• Be careful not to drop the roll and hurt yourself when loading it.
• Be careful not to pinch your fingers between the Roll Holder shaft (a) and the guide grooves (b) when
loading rolls.
Loading Rolls in the Printer
iPF8400SE
User's Guide
Handling and Use of Paper Handling rolls
340
To Next Page
