Replacing the Cutter Unit
1
Open the Top Cover.
2
If the Cutter Unit or Carriage Cover is dirty, use a damp cloth that you have wrung out completely to wipe it
clean.
Important
•
Do not touch the Linear Scale (a), Carriage Shaft
(b), or Fixed Blade (c). This may stain your hands
and damage the printer.
3
Push the Cutter Unit Detachment Lever to the left to un-
lock it.
iPF8400SE
Replacing the Cutter Unit
User's Guide
Maintenance and Consumables Cutter Unit
555
To Next Page
