LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
8- 1 HB1-5273-000 1 COVER, FRONT, RIGHT
2 HG1-4365-000 1 NCU PCB ASSEMBLY
3 HG5-3062-000 1 SCNT BOARD ASS’Y
4 HG5-3071-000 1 MODULAR BOARD ASS’Y
5 HH2-3210-000 1 CABLE, FLAT, 23P
6 HH3-5392-000 1 POWER SUPPLY UNIT
7 XB1-2300-807 10 SCREW, CROSS-RECESS, FCH
8 XB2-7300-607 1 SCREW, M3X6
9 XB4-7300-807 1 SCREW, TAP TIGHT, BINDING HEAD
10 XB6-7300-607 2 SCREW, TP, M3X6
