5-34
Printing Environment Settings
5
SETUP Menu Settings
CONNECT.RECOG.
ON*, OFF
When you print using a network, you may not obtain proper printout results
(unreadable characters are printed, overlay print fails, etc.). In this case, specify
OFF for this item.
EXT.RX BUFFER
OFF*, ON
If this item is set to ON, the memory capacity of the printer's receive buffer that
receives the data is increased. You can speed up the time the computer exits
when you send a large amount of data or complicated data from the computer.
IMPORTANT
After changing the settings for this item, cycle the power of the printer to make the
settings effective.
NOTE
This item is displayed only when an optional RAM module is installed.
USER MAIN. Options
ADJ.START POS.
OFFSET Y(TRAY) ................ -5.0 to 5.0; 0.0* (mm)
OFFSET X(TRAY) ................ -5.0 to 5.0; 0.0* (mm)
OFFSET Y(CASS1).............. -5.0 to 5.0; 0.0* (mm)
OFFSET X(CASS1) ............. -5.0 to 5.0; 0.0* (mm)
OFFSET Y(CASS2)*
1
........... -5.0 to 5.0; 0.0* (mm)
OFFSET X(CASS2)*
1
.......... -5.0 to 5.0; 0.0* (mm)
OFFSET Y(DUP.).................. -5.0 to 5.0; 0.0* (mm)
OFFSET X(DUP.) ................. -5.0 to 5.0; 0.0* (mm)
*1 OFFSET Y(CASS2) and OFFSET X(CASS2) are displayed only when the optional paper feeder is
installed.
Specifies the printing position of the paper in the specified paper source. Adjusts
the position in the vertical direction (Y) or the horizontal direction (X) by the
specified value.
The setting values is indicated in millimeters (mm), and you can adjust the
position in 0.1 mm increments using [ ] and [ ].
If you do not adjust the printing position, specify "0.0" for this item.
