Dimensions of Each Part

Appendix

Dimensions of Each Part

■ Printer unit

• Standard state

• State with the paper feeder installed

(mm)

460 410 158 210

273

445

Paper cassette Face up output tray Multi-purpose tray

(mm)

475 410 158 210

411

445

Paper cassette

Face up output tray

Multi-purpose tray
