Canon MX700 - Printer Maintenance Procedures; Service Engineer Adjustments and Replacements; Customer Maintenance Tasks; Special Tools for Servicing

TABLE OF CONTENTS
1. MAINTENANCE
1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by Service Engineer
1-2. Customer Maintenance
1-3. Special Tools
1-4. Serial Number Location
2. LIST OF ERROR DISPLAY / INDICATION/ TROUBLESHOOTING
2-1. Operator Call Errors
2-2. Service Call Errors
2-3. Fax Errors
2-4. Other Error Messages
2-5. Warnings
2-6. Troubleshooting by Symptom
3. REPAIR
3-1. Notes on Service Part Replacement
3-2. Special Notes on Repair Servicing
(1) Side cover L unit removal
(2) Side cover R unit removal
(3) ADF unit removal
(4) Scanner unit removal
(5) Middle frame unit removal
(6) Cable wiring and connection
(7) Ink tube installation
3-3. Adjustment / Settings
(1) Paper feed motor adjustment
(2) Carriage rail adjustment
(3) Document pressure sheet attachment
(4) Sheet feeder unit adjustment
(5) Front tray paper feed roller cleaning
(6) Grease application
(7) Ink absorber replacement
(8) Ink absorber counter setting
(9) User mode
(10) Service mode
A: Service mode operation
B: Destination settings
C: Ink absorber counter resetting
D: Ink absorber counter setting
E: Button and LCD test
(11) PTT Parameter mode
3-4. Verification Items
(1) Service test print
(2) Ink absorber counter value print
4. MACHINE TRANSPORTATION
MX700
