Canon MX700 - Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by Service Engineer

1. MAINTENANCE
1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement
Consumables by Service Engineer
(1) Adjustment
MX700 TABLE OF CONTENTS
Adjustment Timing Purpose Tool
Approx.
time
EEPROM
initialization
- At logic board replacement To initialize settings None.
Perform in the service
mode.
1 min.
Destination settings
(EEPROM
settings)
- At logic board replacement To set destination. None.
Perform in the service
mode.
1 min.
Ink absorber
counter resetting
(EEPROM
settings)
- At logic board replacement
- At ink absorber replacement
To reset the ink absorber
counter.
None.
Perform in the service
mode.
1 min.
Ink absorber
counter value
setting
(EEPROM
settings)
- At logic board replacement
- At ink absorber replacement
To set the ink amount data in the
ink absorber to the ink absorber
counter.
None.
Perform in the service
mode.
1 min.
Paper feed motor
position adjustment
- At paper feed motor
replacement
To adjust the belt tension.
(Position the paper feed motor
so that the belt is stretched
tight.)
None. 5 min.
Carriage rail
position adjustment
- At carriage unit replacement
- After carriage rail removal
and re-assembly
To adjust the distance between
the print head and paper
(between the carriage and the
platen).
None. 5 min.
Print head
alignment
- At print head replacement
- At logic board replacement
- When print quality is not
satisfying
To secure the dot placement
accuracy.
None. 3 min.
(Manual)
Grease application - At carriage unit or carriage
rail replacement
- At LF earth spring or paper
feed roller replacement
- At PG - AP arm lever
replacement
To maintain sliding properties of
the following items:
- Carriage rail
- LF earth spring
- Eject roller
- PG
- AP arm lever
- FLOIL KG-107A
- IF-20
- MOLYKOTE PG641
1 min.
Ink system function
check
- At logic board replacement
- At spur base replacement
- At carriage unit replacement
To maintain detection
functionality for presence of the
ink tanks and each ink tank
position.
None.
Perform in the service
mode.
1 min.
LCD language
settings
- At logic board replacement To set the language to be
displayed on the LCD.
None.
Perform in the user
mode.
1 min.
Document pressure
sheet position
adjustment
- At document pressure sheet
replacement
- DF Base replacement
Hold the sheet with the long side
down, then position its upper left
corner approx. 1 mm in from the
platen glass reference edges
(back left).
None. 1 min.
